a. 8N1
b. 8N2
c. 8E1
d. 8O1
3. Touch button when “Finished?” is displayed to exit.
Modbus Address
1. Go to Modbus Setup menu and select “Finished?” until Address is displayed.
Address will scroll across display followed by the current Address setting.
2. Hold finger on button to scroll quickly through values or touch button repeatedly to move through values more slowly.
Address options range from 1-247.
3. Touch button when “Finished?” is displayed to exit.
4.2.9 EZ Touch Button
The device has a single button that allows the user to change configurations without the use of a magnet or any other tool.
Disabling the EZ Touch button requires the user to access menus with a magnet or via HART, Modbus, or Bluetooth.
1. Hold finger on button while menu selections scroll across screen.
2. Remove finger when Setup menu appears.
3. Touch button when EZ Touch is displayed.
The current EZ Touch setting is displayed (Enabled or Disabled).
4. To change the EZ Touch availability, touch button to change to the opposite state.
After disabling and selecting “Finished?”, the user will need a magnet to enable the setting. Otherwise it will not be
possible to navigate the S5000 menus.
5. Touch button when "Finished?" is displayed to exit.
4.2.10 Swap Delay
SwapDelay allows the user a brief window to change an XCellsensor without the device going into a fault condition. Once a
sensor is disconnected from the transmitter, the user will have 2minutes to reconnect a sensor. During this time, the device
display and analog output will go to its Maintenance level. If a sensor is reconnected or replaced during the 2minute window,
the new sensor’s countdown sequence will begin and the analog output will remain at the Maintenance level. After the sensor
countdown is complete, the analog output will return to reporting a live gas reading. If a sensor is not reconnected after the
2minute window, the S5000 will enter a fault condition. All XCell Sensors have SwapDelay and do not need to be
disconnected from power while changing sensors. For more details on how to change sensors, see 6.2 Replacing an XCell
Sensor. Swap Delay is enabled on all S5000 transmitters by default.
NOTICE
The transition to maintenance mode during the 2minute Swap Delay window and sensor countdown will not trigger the Fault
Relay. The Fault Relay will only be triggered when the device enters a fault condition.
To change Swap Delay status:
1. Hold finger on button while menu selections scroll across screen.
56
4 Operation US
