5. (First Time Only) Accept pairing by touching button on S5000 display.
Bluetooth Security
The Bluetooth connection is encrypted and secured with a unique six digit pin that must be confirmed on the mobile device and
acknowledged on the detector display. All of the previously paired devices can be erased from the S5000 to provide additional
security and control.
To reset all device pairings:
1. Scroll to Settings.
2. Scroll and select Bluetooth
3. Scroll and select “Reset All”.
4. Select “Continue”.
NOTICE
Reset All will delete all paired device memory. All devices will have to re-initiate pairing at the device.
Bluetooth Tag ID
See 4.3.6 Bluetooth FCC/IC ID to view Bluetooth Tag ID.
4.2.8 Modbus Settings
The Modbus Setup menu consists of three configurable sub menus: Baud Rate, Format and Address.
1. Hold finger on button while menu selections scroll across screen.
2. Remove finger when Setup menu appears.
3. Touch button when Modbus Setup is displayed.
Modbus Baudrate
1. Go to Modbus Setup menu. Baudrate option is the first submenu.
Baudrate will scroll across display followed by the current Baudrate setting.
2. Touch the button to change to one of the following baudrate options:
a. 2400
b. 4800
c. 9600
d. 19K2
e. 38K4
f. 115K
3. Touch button when “Finished?” is displayed to exit.
Modbus Data Format
1. Go to Modbus Setup menu and select “Finished?” until Format is displayed.
Format will scroll across display followed by the current Format setting.
2. Touch the button to change to one of the following format options:
55
US 4 Operation
