MSA S5000 User Manual

NOTE: See CSA Certificate for detailed certification information including possible
limitations to the above information.
*Applicable to S5000 Junction Box only
**nC not applicable to S5000 Junction Box
ATEX/IECEx/INMETRO Hazardous Locations (Sira 17ATEX1048X, Sira 17ATEX4052X, IECEx SIR
17.0016X, NCC18.0097X)
Ex db IIB+H
2
T5/T6* Gb
Ex nA nC** IIC T4/T6* Gc
Ex tb IIIC T85°C Db
NOTE: See ATEX/IECEx Certificates for detailed certification information including
possible limitations to the above information.
*Applicable to S5000 Junction Box only
**nC not applicable to S5000 Junction Box
NOTE: For configurations incorporating cemented covers, IIB+H
2
is replaced by IIC.
Digital Sensor with Frit (Fine Threads) Digital Sensor without Frit (Coarse
Threads)
U.S. Division Hazardous Locations as defined
by the NEC:
Class I, Division 1 & 2, Groups A, B, C, D; T5
Class II, Division 1, Groups E, F, G; Class III;
T5
U.S. Division Hazardous Locations as defined
by the NEC:
Class I, Division 2, Groups A, B, C, D; T5
U.S. Zone Hazardous Locations as defined by
the NEC:
Class I, Zone 1, AEx db IIC T5 Gb
Class I, Zone 2, AEx db nA IIC T5 Gc
Zone 21, AEx tb IIIC T85°C Db
U.S. Zone Hazardous Locations as defined by
the NEC:
Class I, Zone 2, AEx nA IIC T5 Gc
Canadian Division Hazardous Locations as
defined by the CEC:
Class I, Division 1 & 2, Groups A, B, C, D; T5
Class II, Division 1, Groups E, F, G; Class III,
T5
Canadian Division Hazardous Locations as
defined by the CEC:
Class I, Division 2, Groups A, B, C, D; T5
Canadian Zone Hazardous Locations as defined
by the CEC:
Ex db IIC T5 Gb
Ex db nA IIC T5 Gc
Canadian Zone Hazardous Locations as defined
by the CEC:
Ex nA IIC T5 Gc
92
US
9 Appendix: General Certification
Information
