1-3
Getting Started
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 2 serial ports (COM A + COM B)
- 1 parallel port supports SPP/EPP/ECP mode
- 1 audio port (Line-in, Line-out, Mic-in).
- 6 high speed USB 2.0 ports (Rear * 4/ Front * 2)
- 1 IrDA connector for SIR.
- 1 RJ-45 LAN jack (Optional).
- 1 S-Bracket pin header.
- 1 D-Bracket
TM
2 pin header.
- 1 Bluetooth pin header.
Audio
h AC97 link controller integrated in SiS
®
963L chipset.
h 6-channel audio codec RealTek ALC655.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.
- Can support SPDIF Out via S-Bracket only.
LAN (Optional)
h SiS963L integrated MAC + RealTek 8201BL PHY.
- Supports 10Mbps and 100Mbps auto-negotiation operation.
- Supports ACPI power management.
BIOS
h The mainboard BIOS provides “Plug & Play” BIOS which detects the
peripheral devices and expansion cards of the board automatically.
h The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
h ATX Form Factor: 30.5 cm (L) x 22 cm (W).
Mounting
h 6 mounting holes.
