Smart D-LED
Voice Speaker Select Output Jumper: JSPK
The mainboard provides a Smart D-LED voice function which help users be
aware of their mainboard conditions. This jumper will enable the Smart D-
LED voice through the case speaker/buzzer and transferred it to the audio
speaker. Refer to chapter 2-29 for Diagnostic LED & Smart D-LED voice
function table.
JP4
1
3
Enable
Buzzer
(Default)
Enable
Speaker
1
3
1
3
