MSI 694 MASTER - Hardware Monitor Setup

CHAPTER 3
AMI
®
BIOS USERS GUIDE
3-22
Hardware Monitor Setup
1. Press <ENTER> on “Hardware Monitor Setup” of the main menu
screen.
2. Use <up> and <down> to choose the item and <PgUp> and
<PgDn> keys to modify the highlighted item.
3. After you have finished with the Peripheral Setup, press <ESC> to
go back to the main menu.
AMIBIOS SETUP - Hardware Monitor Setup
(C) 1999 American Megatrends, Inc. All Rights Reserved
ESC:Exit
F1 :Help
F5 :Old Values
F6 :Load BIOS Defaults
F7 :Load Setup Defauls
↑ ↓ → ←↑ ↓ → ←
↑ ↓ → ←↑ ↓ → ←
↑ ↓ → ← :Select Item
PU/PD/+/-:Modify
(Shift)F2:Color
Spread Spectrum :Enabled
CPU FSB Clock (MHz) :Auto
CPU Ratio Selection :3.0X
CPU Vcore Selection (V) :Auto
-= System Monitor =-
Current CPU Temperature :45
o
C/113
o
F
Current System Temperature :32
o
C/89
o
F
Current CPU Fan Speed :5200 RPM
Current Chassis Fan Speed :0 RPM
Vcore :2.112V
+2.500V :2.575V
+3.300V :3.373V
+5.000V :4.946V
+12.000V :11.986V
