CHAPTER 3
AMI
®
BIOS USERS GUIDE
3-9
Chipset Features Setup
1. Press <ENTER> on “Chipset Features Setup” of the main menu
screen.
2. Use <Up> and <Down> to choose the item and <PgUp> and
<PgDn> keys to modify the highlighted item.
3. After you have finished with the Chipset Features Setup, press
<ESC> to go back to the main menu.
AMIBIOS SETUP - CHIPSET FEATURES SETUP
(C) 1999 American Megatrends, Inc. All Rights Reserved
ESC:Exit
F1 :Help
F5 :Old Values
F6 :Load BIOS Defaults
F7 :Load Setup Defauls
↑ ↓ → ←↑ ↓ → ←
↑ ↓ → ←↑ ↓ → ←
↑ ↓ → ←:Select Item
PU/PD/+/-:Modify
(Shift)F2:Color
Set SDRAM Timing by SPD :Disabled
DRAM Frequency :HCLK
SDRAM CAS# Latency :3
DRAM Integrity Mode :Disabled
CPU In Order Queue :4-Level
Memory Hole :Disabled
AGP Mode :Auto
AGP Driving :Auto
AGP Driving Manual :CB
AGP Aperture Size :64MB
