CHAPTER 2 HARDWARE INSTALLATION
2-32
Modem-In: JPH
This connector is for Modem with internal voice connector.
Mono_Out is connected to the Modem Speaker Out connector.
Phone_In is connected to the Modem Microphone In connector.
JPH
Mono_Out
GND
Phone_In
