MSI H61MA-E35 (B3) - Mainboard Specifications

1-2
Gettng Started
Manboard Spec󰘰catons
Processor Support
Intel
®
Core
TM
7/ Core
TM
5 /Core
TM
3/ Pentum
®
/ Celeron
®
processor n the LGA1155
package
(For the latest nformaton about CPU, please vst
http://www.ms.com/servce/cpu-support)
Chpset
Intel
®
H61 (B3) chpset
Memory Support
2 DDR3 DIMMs support DDR3 1333/ 1066 DRAM (16GB Max)
Supports Dual-Channel mode
(For more nformaton on compatble components, please vst
http://www.ms.com/servce/test-report/)
LAN
Supports LAN 10/100/1000 by Realtek
®
RTL8111E (H61MA-E35 (B3))
Supports LAN 10/100 by Realtek
®
RTL8105E (H61M-E21 (B3))
Audo
Chp ntegrated by Realtek
®
ALC887
Flexble 8-channel audo wth jack sensng
Complant wth Azala 1.0 Spec
SATA
4 SATA 3Gb/s ports by Intel
®
H61 (B3)
2 SATA 6Gb/s ports by ASMeda
®
ASM1061 (H61MA-E35 (B3))
Connectors
Back panel
1 PS/2 keyboard/mouse port
4 USB 2.0 ports
2 USB 3.0 ports (H61MA-E35 (B3))
1 HDMI port*
1 VGA port*
1 DVI-D port*
1 LAN port
6 󰘱exble audo ports (H61MA-E35 (B3))
3 󰘱exble audo ports (H61M-E21 (B3))
*(The HDMI, DVI and VGA ports only work wth Integrated Graphcs Processor)
On-Board
2 USB 2.0 connectors
1 Chasss Intruson connector
1 S/PDIF-Out connector
1 Front Panel Audo connector
1 TPM Module connector
1 Seral connector
■
■
■
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
