2-14
Hardware Setup
MS-7740
Chapter 2
Hardware Setup
MS-7740
Chapter 2
Front USB Connector: JUSB1~2
Ths connector, complant wth Intel
®
I/O Connectvty Desgn Gude, s deal for con-
nectng hgh-speed USB nterface perpherals such as USB HDD, dgtal cameras, MP3
players, prnters, modems and the lke.
11
5V
1.VC
C
3.USB0
-
10.NC
5.USB0
+
7
.Ground
9.No
Pin
8
.Ground
6.USB1
+
4.USB1
-
2.VC
C
* The MB layout n ths 󰘰gure s for reference only.
USB Bracket (optonal)
Important
Note that the pns of VCC and GND must be connected correctly to avod possble
damage.
Front Panel Audo Connector: JAUD1
Ths connector allows you to connect the front panel audo and s complant wth Intel
®
Front Panel I/O Connectvty Desgn Gude.
1.MI
C L
3.MI
C R
10.Head
P
hone
Detection
5.Head P
hone
R
7.SENSE_SEN
D
9.Head
P
hone
L
8.No
Pi
n
6.MI
C D
etection
4.NC
2
.Ground
