MSI H67MS-E33 series - Connectors Overview; Expansion Slots; Form Factor and Mounting

1-3
MS-7680
Chapter 1
Connectors
Back panel
1 PS/2 keyboard port
1 PS/2 mouse port
6 USB 2.0 ports
1 HDMI port*
1 VGA port*
1 DVI-D port*
1 LAN port
6 󰘱exble audo ports
*(The HDMI, DVI-D and VGA ports only work wth Integrated Graphcs Processor)
On-Board
4 USB 2.0 connectors
1 Chasss Intruson connector
1 S/PDIF-Out connector
1 Front Panel Audo connector
1 TPM Module connector
1 Parallel port connector
1 Seral port connector
Slots
1 PCIE x16 slot
3 PCIE x1 slots
Form Factor
Mcro-ATX (24.5 cm X 21.0 cm)
Mountng
6 mountng holes
■
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
■
■
■
■
