MSI H67MS-E33 series User Manual

Hardware Setup
MS-7680
Chapter 2
2-11
Hardware Setup
MS-7680
Chapter 2
Back Panel
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
USB 2.0 Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces. Supports data transfer rate up to 480Mbt/s
(H-Speed).
HDMI Port
The Hgh-De󰘰nton Multmeda Interface (HDMI) s an all-dgtal audo/vdeo nterface
capable of transmttng uncompressed streams. HDMI supports all TV format, nclud
-
ng standard, enhanced, or hgh-de󰘰nton vdeo, plus mult-channel dgtal audo on a
sngle cable.
VGA Port
The DB15-pn female connector s provded for montor.
DVI-D Port
The DVI-D (Dgtal Vsual Interface-Dgtal) connector allows you to connect a LCD
montor. It provdes a hgh-speed dgtal nterconnecton between the computer and ts
dsplay devce. To connect an LCD montor, smply plug your montor cable nto the DVI
connector, and make sure that the other end of the cable s properly connected to your
montor (refer to your montor manual for more nformaton.)
Important
The HDMI, VGA and DVI-D dsplay nterfaces on the manboard are desgned to serve
as IGP (Integrated Graphcs Processor) used. If you nstalled a processor wthout
ntegrated graphcs chp, these dsplay ports wll have no e󰘯ect.
▶
▶
▶
▶
▶
Keyboard HDMI Port
LAN
Lne-In
Lne-Out
Mc
VGA Port
USB 2.0 Port
DVI-D Port
RS-Out
CS-Out
SS-Out
USB 2.0 Port
Mouse
USB 2.0 Port
