MSI H67MS-E33 series - Memory Module Installation

2-8
Hardware Setup
MS-7680
Chapter 2
Hardware Setup
MS-7680
Chapter 2
Memory
These DIMM slots are used for nstallng memory modules. For more nformaton on
compatble components, please vst http://www.ms.com/ndex.php?func=testreport
DDR3
240-pn, 1.5V
48x2=96 pn 72x2=144 pn
Dual-Channel mode Populaton Rule
In Dual-Channel mode, the memory modules can transmt and receve data wth two
data bus lnes smultaneously. Enablng Dual-Channel mode can enhance the system
performance. The followng llustratons explan the populaton rules for Dual-Channel
mode.
DIMM1
DIMM2
Important
DDR3 memory modules are not nterchangeable wth DDR2, and the DDR3 standard
s not backwards compatble. You should always nstall DDR3 memory modules n
the DDR3 DIMM slots.
In Dual-Channel mode, make sure that you nstall memory modules of the
same type
and densty n d󰘯erent channel DIMM slots.
Due to the chpset resource deployment, the system densty wll only be detected up
to 7+GB (not full 8GB) when each DIMM s nstalled wth a 4GB memory module.
•
•
•
Installed
Empty
