1-3
Getting Started
IEEE 1394 (Optional)
Supports up to 2 * 1394 ports (Rear * 1/ onboard header * 1).
Transfer rate is up to 400Mbps
Controlled by VIA 6307 chipset
Audio
AC’97 link controller integrated in VIA VT8237.
6 channels software audio codec ALC655.
- Compliance with AC97 v2.3 Spec.
- Meet PC2001 audio performance requirement.
LAN
VIA VT8237 MAC + VIA 6103 Ethernet PHY
- Supports 10/100Mb/s auto-negotiation operation.
- Compliant with PCI v2.2 and PC99 standard.
- Supports ACPI Power Management.
BIOS
The mainboard BIOS provides “Plug & Play” BIOS which detects the peripheral
devices and expansion cards of the board automatically.
The mainboard provides a Desktop Management Interface (DMI) function which
records your mainboard specifications.
Dimension
Micro-ATX Form Factor: 24.5 cm (L) x 24.5 cm (W).
