MSI MEG X570 UNIFY

20
Overview of Components
For 2nd Gen AMD Ryzen™
Slot Single 2-Way 3-Way*
PCI_E1 (CPU) @3.0 x16 @3.0 x8 @3.0 x8
PCI_E2 (PCH) 3.0 x1 — 3.0 x1 — 3.0 x1 —
PCI_E3 (CPU) — @3.0 x8 @3.0 x8
PCI_E4 (PCH) — 3.0 x1 — 3.0 x1 — 3.0 x1
PCI_E5 (PCH) 3.0 x4 3.0 x4 @3.0 x4
(─: unavailable, @: graphics card, *: CrossFire only)
For Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™
Graphics
Slot Single 2-Way*
PCI_E1 (CPU) @3.0 x8 @3.0 x8
PCI_E2 (PCH) 3.0 x1 — 3.0 x1 —
PCI_E3 (CPU) — —
PCI_E4 (PCH) — 3.0 x1 — 3.0 x1
PCI_E5 (PCH) 3.0 x4 @3.0 x4
(─: unavailable, @: graphics card, *: CrossFire only)
