40
5. Insert your M.2 SSDs into M.2 slots at a 30-degree angle.
30º30º
6. Please follow the below instructions according to your SSD length.
• Installing 2260/2280 SSD into M2_5 slot
Rotate the EZ M.2 Clip to fix the M.2 SSDs.
2280 SSD
2260/2280 SSD
66
66
• Install 22110 SSD into M2_5 slot
Secure the M.2 SSDs with the supplied M.2 screw.
66
2280 SSD
22110 SSD
To Next Page
