En-10
MS-7760 Manboard
7. Close the actve lever wth a smooth unform moton and latch to the socket.
8. Close the hnge lever wth a smooth unform moton and latch to the socket.
5. Lne up the CPU to 󰘰t the CPU socket. Be sure to hold the CPU by the base wth the
metal contacts facng downward. The algnment keys on the CPU wll lne up wth
the edges of the CPU socket to ensure a correct 󰘰t.
6. Carefully close the load plate and remove the plastc protectve cap.
Algnment Key
