Hybrd Dgtal Power
Press <Enter> to enter the sub-menu.
CPU Core Vdroop O󰘯set Control
Ths tem s used to select the o󰘯set level of CPU core voltage when the CPU core
voltage droops from full-/ over-loadng of CPU. Hgher o󰘯set percentage wll be more
helpful for extreme overclockng. [Auto] s the default for hgher power e󰘲cency.
System Agent Vdroop O󰘯set Control
Ths tem s used to select the o󰘯set level of system agent unt voltage when the
system agent unt voltage voltage droops from full-/ over-loadng. Hgher o󰘯set
percentage wll be more helpful for extreme overclockng. [Auto] s the default for
hgher power e󰘲cency.
Dgtal Compensaton Level
Ths tem s used to set the dgtal o󰘯set level of current. [Auto] s the default that
keeps normal operatng for most usage. Opton [Hgh] provdes better performance
on current stablty whle overclockng.
CPU Core OCP Expander
Ths tem s used to expand the lmtaton of CPU current protecton. [Default] s the
default opton for regular protecton. [Enhanced] s for overclockng purpose, but
please note that the hgher expandng value ndcates less protecton.
System Agent OCP Expander
Ths tem s used to expand the lmtaton of system agent current protecton. [Default]
s the default opton for regular protecton. [Enhanced] s for overclockng purpose,
but please note that the hgher expandng value ndcates less protecton.
CPU Core Swtchng Frequency
Ths tem allows you to ncrease PWM workng speed to stablze CPU core voltage
and mnmze rpple range.
Note: The hgher value wll cause hotter MOSFET, please make sure the coolng
soluton on MOSFET s well-prepared before you ncrease the value.
System Agent Swtchng Frequency
Ths tem allows you to ncrease PWM workng speed to stablze system agent
voltage and mnmze rpple range.
Note: The hgher value wll cause hotter MOSFET, please make sure the coolng
soluton on MOSFET s well-prepared before you ncrease the value.
CPU Core Voltage/ System Agent Voltage (SA)/ CPU I/O Voltage/ CPU PLL Voltage/
CPU Overrde Voltage/ DDR CH_A/B Voltage/ DDR CH_C/D Voltage/ DDR CH_A CA
Vref Voltage/ DDR CH_B CA Vref Voltage/ DDR CH_C CA Vref Voltage/ DDR CH_D
CA Vref Voltage/ DDR CH_A DQ Vref Voltage/ DDR CH_B DQ Vref Voltage/ DDR CH_
C DQ Vref Voltage/ DDR CH_D DQ Vref Voltage/ PCH 1.1 Voltage/ PCH 1.5 Voltage
These tems are used to adjust the voltages.
Current CPU Core Voltage/ Current SA Voltage/ Current CPU I/O Voltage/ Current
CPU PLL Voltage/ Current DDR CH_A/B Voltage/ Current DDR CH_C/D Voltage
These tems show current voltages. Read-only.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
