mspa Lite Bubble Spa - How to Replace the Check Valve

2016 MSpa Service Manual
MSpa website: www.the-mspa.com
- 16 -
5. Take out control box from spa pool
6. Remove the foam
7. Loosen four screws on the top lid
8. Disassemble the mid part of the control box
9. Dismantle the fixed seat of pump lead;
10. Unscrew four screws that fasten bubble generator
onto the control box.
11.Cut off bindings and Heat shirnkable sleeving,
dismantle the pump lead;
12. Take out the original bubble generator from the
control box and assemble the new one in reverse order.
4.6 How to Replace the Check Valve
1. Remove the control panel
2. Turn the control box inside the spa pool upside down，
Unscrew the check valve plastic nut
