2016 MSpa
Service Manual
MSpa website: www.the-mspa.com
- 17 -
3. Unscrew three screws that fix the check valve
4. Tak e o ut the original check valve and put the seal ring
in good condition.
5. Assemble a new check valve by screws in reverse
order.
4.7 How to Replace the Transformer
1. Take off water inlet and outlet caps
2. Remove the control panel
4. Unscrew the check valve plastic nut
5. Take out control box from spa pool
7. Loosen four screws on the top lid
8. Disassemble the mid part of the control box
The$upper$square$valve$is$for$inflation$
The$button$round$valve$is$for$deflation$
$
