MTD 1332G - Page 11

11
1336G / 36" Deck Assembly
- Parts List for Figure 6
Ref.
No. Part No. Description Qty.
1-- -- --
2 00006168 Flat Washer, 3/8 Zinc 5
3 01001371 Hex Cap Screw, 3/8-16, 2.75 2
4 00012158 Flat Washer, 3/8 Zinc 2
5 00012173 Lock Nut, Nylon Insert, 3/8-16 10
6 00012402 Shim Washer 1
7 00012428 Lock Nut, Nylon Insert, 1/2-13 6
8 00013433 Hex Nut, 5/16-18 1
9 00014439 Shoulder Bolt 1
10 00014459 Eye Bolt, Right Hand 1
11 00018468 Cap, Black Vinyl 5
12 00021958 Grease Fitting, 1/4-28 45° 1
13 00019271 Eye Bolt, Left Hand 1
14 00019554 Turnbuckle 1
15 00021895 Idler Arm 1
16 00021956 Hair Pin, 3/8"-1/2" 2
17 00021961
E-Ring, Retainer 1
18 00021970 Pulley Deck 2
19 00021977 Idler Deck Take-up 1
20 00030633 Decal Rotating Blade 1
21 01005045 Deck Stiffener 1
22 00030635 Decal, Warning Shield Missing 1
23 00034224 Lock Nut, 3/8-16 2
24 00050441 Belt Drive 1
25 00062715 Turnbuckle, Sleeve 2
26 01000160 Spacer, Belt Guide 5
27 01000517 Carriage Bolt, 1/2-13 x 1-1/4 6
28 01000643 Carriage Bolt, 3/8-16 x 2 2
29 01000644 Carriage Bolt, 3/8-16 x 4.5 5
30 01001069 Deck 36" 1
31 01002152 Bar Weight 1
32 01002011 Carriage Bolt, 3/8-16 x 1-1/2 2
33 01003154 Clutch Link 1
34 01002103 Blade Deck Clutch Rod 1
35 01002166 Decal, Danger Hands and Feet 1
36 00063043 Idler Base 1
37 -- -- --
