MTD 1332G - 1332 G, 1336 G; 32 & 36 Chute Assembly

7
1332G, 1336G / 32" & 36" Chute Assembly
- Figure 3 & Parts List
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, 5/32 x 1 1/2 Zinc 1
2 00012158 Flat Washer, 3/8, Zinc 1
3 00013597 Decal, Cut Line 1
4 00030644 Pin, Deflector Assembly, Weldment1 1
5 01002037 Torsion Spring 1
601004047Chute Assembly Discharge1
1
2
3
4
6
5
