MTD 75 series User Manual

Crankshaft, piston and connecting rod
105
15. Push the piston out of the cylinder.
16. Remove the piston rings from the piston using a pair
of piston ring pliers. See Figure 10.5.
17. Remove the crank shaft. See Figure 10.6.
Figure 10.5
Piston ring pliers
Figure 10.6
Remove the
crankshaft
