MTS Sensors Temposonics G Series - Technical Data Temposonics GTE Analog ATEX; NEC; CEC

12
Temposonics
®
GTE Analog ATEX / NEC / CEC
Operation Manual
7. Technical data Temposonics
®
GTE Analog ATEX / NEC / CEC
Output
Voltage 0…10 VDC, 10…0 VDC, −10…+10 VDC, +10…−10 VDC
(minimum controller load: > 5k Ω)
Current 4…20 mA, 20…4 mA, 0…20 mA, 20…0 mA
(minimum/maximum load: 0/500 Ω)
Measured value Position
Measurement parameters
Resolution: Position Infinite (restricted by output ripple)
Cycle time < 1 ms (typical)
Linearity deviation < ±0.02 % F.S. (minimum ±50 μm)
Repeatability < ±0.001 % F.S. (minimum ±2.5 µm)
Hysteresis < 4 µm
Operating conditions
Operating temperature
–40…+75 °C (−40…+167 °F)
Humidity 90 % relative humidity, no condensation
Ingress protection IP64
Shock test 100 g (single shock) according to IEC 60068-2-27 (survivability)
Vibration test 10 g/10…2000 Hz according to IEC 60068-2-6 (resonance frequencies excluded)
EMC test Electromagnetic emission according to EN 61326-1 and EN 55011
Electromagnetic immunity according to EN 61326-1
The sensor meets the requirements of the EC directives and is marked with
.
Operating pressure 350 bar static (5076 psi static), 690 bar peak (10,000 psi peak)
Agency approvals (optional)
Non-sparking Class I Zone 2 AEx/Ex nA IIC T4 Gc
Class II / III Zone 22 AEx tc / Ex tc IIC T130 °C Dc
Class I / II / III Div 2 T4 ABCDEFG
II 3G Ex nA IIC T4 Gc
IECEx BVS 13.0063X
–20 °C ≤ T
amb
≤ +75 °C (–4 °F ≤ T
amb
≤ +167 °F)
Design / Material
Sensor electronics housing Stainless steel 1.4305 (AISI 303)
Sensor rod Stainless steel 1.4306 (AISI 304L)
Stroke length 50…2540 mm (2…100 in.)
Mechanical mounting
Mounting position Any
Mounting instruction
Please consult the technical drawing on page 9
Electrical connection
Connection type Cable output
Operating voltage +24 VDC (−15/+20 %)
Current consumption 100 mA typical per channel
Dielectric strength 700 VDC (DC ground to machine ground)
Polarity protection Up to −30 VDC
Overvoltage protection Up to 36 VDC
LR1346-4
