Temposonics
®
GTE Analog ATEX / NEC / CEC
Operation Manual
3. Identication
3.1 Order code of Temposonics
®
GTE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
G
T
E B 0 1
a b c d e f
optional
a Sensor model
G T E Embedded pressure- t  ange Ø 60 mm (2.36 in.)
b Stroke length
X X X X M
0050…2540 mm
Standard stroke length (mm) Ordering steps
50… 500 mm 5 mm
500… 750 mm 10 mm
750…1000 mm 25 mm
1000…2540 mm 50 mm
X X X X
U
002.0…100.0 in.
Standard stroke length (in.) Ordering steps
2… 20 in. 0.2 in.
20… 30 in. 0.4 in.
30… 40 in. 1.0 in.
40…100 in. 2.0 in.
Non-standard stroke lengths are available;
must be encoded in 5 mm/0.1 in. increments.
.
c Connection type
B 0
1
1 m/3 ft. TPV cable (part no. 530 162)
B 0
3
3 m/10 ft. TPV cable (part no. 530 162)
B 0
5
5 m/16 ft. TPV cable (part no. 530 162)
d Operating voltage
1
+24 VDC (–15/+20 %) (T
amb
max. +75 °C (+167 °F))
e Output
A
0
4…20 mA
A 1
20…4 mA
A 2
0…20 mA
A 3
20…0 mA
V
0
0…+10 VDC
V 1
+10…0 VDC
V 2
−10…+10 VDC
V 3
+10…−10 VDC
Optional:
f Agency approval
E X
Approved version
