Communications
The host communication port baud rate is shown. Press the MODE or ± key to change
the baud rate selection (300, 1200, 2400, 4800, 9600, 19200).
The communication mode for remote data access is shown. Press the MODE or ± key to
change the selected communication mode. The available choices are shown below. See
section 19 of this manual for additional communication protocol information.
Standard Level Plus ASCII Communication Protocol modes
HOST PORT ADDR = A
thru
HOST PORT ADDR = R
MTS DDA Emulation Modes
MTS DDA (C0 - C7)
MTS DDA (C8 - CF)
MTS DDA (D0 - D7)
MTS DDA (D8 - DF)
MTS DDA (E0 - E7)
MTS DDA (E8 - EF)
MTS DDA (F0 - F7)
MTS DDA (F8 - FF)
EIA232 Printer modes
PRINT ON TIME
PRINT ON ALARM
PRINT ON TIME & ALARM
NOTE
For EIA 232 printer modes, the Level Plus monitor
requires an 80 column printer with a minimum
buffer size of 1K (thousand) bytes.
SELECT COM PORT MODE
HOST PORT ADDR = A
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
SELECT COM BAUD RATE
9600
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
