Temperature Display
The temperature display function can be enabled or disabled. Press the MODE or +/- key
to enable and select the desired temperature resolution. Press the ENTER key to continue.
The available selections for the temperature enable screen include:
• OFF (DISABLED)
• LOW RES (1 F)
• MED RES (0.2 F)
• HI RES (0.02 F)
• FAST TEMP (1 F)
Alarms and Relays
The enable status for TANK #1 PRODUCT HiHi software alarm is shown. Press the MODE
key to ENABLE or DISABLE the selected alarm. The available programmable software
alarms are:
• Product HiHi
• Product High
• Product Low
• Product LoLo
• Interface High (if 2 floats are specified)
• Interface Low (if 2 floats are specified)
• Temperature High (if temperature function enabled)
• Temperature Low (if temperature function enabled)
• Gauge Error (used to signal inoperative tank gauges)
• STI Error (used to signal inoperative STI modules)
NOTE
FAST TEMP selection uses a special non filtered DDA
tank gauge temperature command to reduce the time
delays associated with temperature updates. Since the
tank gauge temperature output for this mode is not fil-
tered the possibility of temperature jumps could exist
in noisy environments. The Level Plus monitor soft-
ware limits any temperature changes to a maximum
of 5 degrees (F) between updates. FAST TEMP mode
will only work with DDA tank gauge software versions
1.04 and later.
NOTE
The enabling and selected resolution of the tempera-
ture function will directly affect the tank gauge (sen-
sor) scan rate. See Appendix C of this manual for
additional information about calculating system scan
rates.
TANK#1 TEMPERATURE
MED RES (O.2 F)
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
48
