Use the number keys to optionally assign software alarms to specific relays and press the
ENTER key. Multiple alarm assignments to any or all relays is permissible. The eight
available relays are referenced as RELAY #0 to RELAY #7.
The limit value for TANK #1 PRODUCT HiHi alarm is shown. Press the MODE key to
change the value or the ENTER key to continue.
Use the number keys to type a new alarm limit value and press the ENTER key.
Each alarm limit can be assigned an independent hysteresis value. The programmable
hysteresis function is useful for relay control applications that require a programmed hys-
teresis (or dead-band) around the set point. Press the MODE key to enable/disable the
programmable hysteresis function.
The value for TANK #1 PRODUCT HiHi hysteresis is shown. Press the MODE key to
change or the ENTER key to continue.
TK#1 PROD HiHi HYST.
DISABLED (OFF)
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TK#1 PROD HiHi LIMIT
------ in.
‘Enter’ NEW VALUE
TK#1 PROD HiHi LIMIT
0.000 in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TK#1 PROD HiHi ALARM
RELAY ASSIGNMENT:
- 1 - - - - - -
TYPE RELY# TO TOGGLE
TK#1 PROD HiHi ALARM
ENABLED (ON)
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
49
