Safe Fill
The safe fill capacity for tank #1 is shown. If you wish to change this value press the
MODE key.
Use the number keys to change the safe fill value and press the ENTER key.
Max Safe Fill
The maximum safe fill capacity for tank #1 is shown. If you wish to change this value
press the MODE key.
Use the number keys to change the maximum safe fill value and press the ENTER key.
The volumetric calculation system requires the user to input tank height versus tank vol-
ume information. The Level Plus monitor currently supports GAUGE TABLES (strapping
tables) or equations for SPHERE type vessels. Select the desired type of STRAP MODE by
pressing the MODE key.
TANK #1 STRAP MODE
STRAP TABLE
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TANK #1 MAX SAF FILL
-------- gal
‘Enter’ NEW VALUE
TANK #1 MAX SAF FILL
100095 gal
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TANK #1 SAFE FILL
-------- gal
‘Enter’ NEW VALUE
TANK #1 SAFE FILL
100090 gal
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
62
