The current SPHERE radius length is shown Press the MODE key to change the current
value or press ENTER to continue.
The SPHERE offset parameter is used to add or subtract a fixed volume from the equation
calculated sphere volume. This parameter is typically used to account for volume errors
created by non-uniform sphere geometries (i.e. flat bottoms or internal structures). Press
the MODE key to change the current offset value or press ENTER to continue. Press the
+/- key to change the ADD/SUB (subtract) indicator.
If SPHERE STRAP MODE was previously selected, the SPHERE OFFSET parameter is the
last volumetric parameter to program. Pressing ENTER will return the user to the STRAP
MODE menu. The user may use the FNCTN (function) key to back up through the vol-
ume parameter screens or press the CLEAR key to proceed to the system exit menu.
Strap Table (Only if STRAP TABLE MODE selected)
The strap table is used to define the tank volume versus tank height information to the
volumetric calculation system.
The number of entries for tank #1 strap table is shown. If you wish to change this num-
ber press the MODE key.
Use the number keys to change the number of entries for tank #1 gauge table and press the
ENTER key. Table sizes can range from 2 to 100 entries.
TANK #1 STRAP TABLE
SIZE: --- (2-100)
‘Enter’ NEW VALUE
TANK #1 STRAP TABLE
SIZE: 3
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TANK #1 SPHERE OFF.
ADD 0 gal
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
TANK #1 SPHERE RAD.
700 in.
‘Mode’ TO CHANGE
‘Enter’ TO CONTINUE
NOTE
If STRAP TABLE mode is selected, proceed to STRAP
TABLE section of manual.
