The LPM MEMORY TRANSFER function is used to upload or download the contents of the Level
Plus Monitor’s non-volatile EEPROM memory in 2-kilobyte pages for archive purposes or to copy
memory from one monitor to another. The user must have MTS DDASETUP software running on
an IBM compatible PC to perform the memory transfer. Contact MTS Technical Support for addi-
tional information on the use of this function.
The memory transfer screen is displayed.
Press the ‘Mode’ key to start the transfer operation. The following screen is displayed.
Use the number keys (0-3) to select the 2-kilobyte EEPROM memory page to transfer. Note that
the memory transfer procedure must be repeated for all EEPROM memory pages (0-3).
The following screen is displayed.
Use the number keys to select the transfer direction. If ‘LPM->HOST” is selected, the following
screen is displayed, where PAGE X refers to the memory page (0-3) chosen above.
LPM MEMORY TRANSFER
LPM->HOST (PAGE X)
WAITING FOR HOST
‘Clear’ TO EXIT
LPM MEMORY TRANSFER
1 = LPM->HOST
2 = HOST->LPM
‘Clear’ TO EXIT
LPM MEMORY TRANSFER
SELECT EEPROM PAGE #
(0-3)
‘Clear’ TO EXIT
LPM MEMORY TRANSFER
‘Mode’ TO START
‘Enter’ TO CONTINUE
73
