15
6.1 Specifications of Analog System Components
6.1a Analog Personality Module (APM)
Parameter Specification
Power Requirements: ± 13.5 Vdc to ± 15 Vdc at 190 mA maximum, 115 mA minimum
Output Impedance: 10 K½ minimum load for voltage output
Output: Specified by user; Range: - 10 Vdc to + 10 Vdc, forward or reverse acting
Temperature Requirements:
Storage: - 40 to 150°F (- 40 to 70°C)
Operating: - 32 to 150°F (-30 to 70°C)
Coefficient: 10 ppm/°F (18 ppm °C)
Maximum Cable Length: 150 ft.
Standard Features: Field programmable
Specifications are subject to change without notice. Consult MTS for verification of specifications critical to your application.
6.1b Analog Output Module (AOM) and Analog Output Card
Parameter Specification
Power Requirements:
Standard: + 15 Vdc (±2%) at 250 mA, < 1% ripple
- 15 Vdc (±2%) at 65 mA, < 1% ripple
Optional: + 24 Vdc (±2%) at 340 mA, < 1% ripple
Output Impedance: 5 K½ minimum load for voltage output, 400½ maximum for 4-20 mA output
Velocity Output: 0 to ± 10 Vdc at 1 to 400 in. per second
Positive voltage output as magnet travels away from the transducer's head assembly, negative
voltage output as the magnet travels toward the transducer's head assembly.
Temperature Requirements:
Storage: - 40 to 180°F (- 40 to 82°C)
Operating: - 40 to 180°F (- 40 to 82°C)
Coefficient: 20 ppm/°F (36 ppm/°C)
Standard Features: Non-volatile memory permanently stores set-up information. Surface mounted components
reduce moment of inertia and enhance shock and vibration resistance of the module.
Specifications are subject to change without notice. Consult MTS for verification of specifications critical to your application.
