6.2 Crankcase Breather
6.2.1 Crankcase breather – Oil mist fine separator replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Engine oil
Oil mist fine separator
(→ Spare Parts Catalog)
O-ring
(→ Spare Parts Catalog)
WARNING
Hot oil.
Oil can contain combustion residues which are harmful to health.
Risk of injury and poisoning!
• Wear protective clothing, gloves, and goggles / safety mask.
• Avoid contact with skin.
• Do not inhale oil vapor.
Replacing oil mist fine separator
1. Loosen screws (1) and remove together
with retainer (2).
2. Replace oil mist fine separator (3).
3. Check O-ring (4), replace if necessary.
4. Replace further oil mist fine separators in
the same way.
MS150094/01E 2012-08 | Task Description | 43
TIM-ID: 0000018590 - 005
