MTU 16V 2000 C66 - Cylinder Head Cover - Removal and Installation

6.3.2 Cylinder head cover – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 8-40 Nm
F30043446 1
Ratchet
F30027340 1
Gasket
(→ Spare Parts Catalog)
Preparatory steps
1. On cylinder head covers with crankcase breather: Loosen clamps.
2. Slide rubber sleeves onto the pipe.
Cylinder head cover – Removal
and installation
1. Remove cylinder head cover with gasket
from cylinder head.
2. Clean installation surface.
3. Check condition of gasket in cylinder head
cover.
4. Replace damaged gasket(s).
5. Install cylinder head cover with screws.
Final steps
1. Slide rubber sleeves onto the relevant pipe connection.
2. Tighten all clamps.
MS150094/01E 2012-08 | Task Description | 47
TIM-ID: 0000000019 - 003
