6.15 Battery-Charging Generator
6.15.1 Battery-charging generator drive – Drive belt replacement
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Mandrel
8205892861/08 1
Preparatory steps
1. Remove safety equipment (if fitted).
2. Remove screws of protective cover (engine free end).
3. Remove protective cover.
Drive belt – Replacement
1. Hold adjusting lever at square.
2. Rotate adjusting lever until drive belt is released.
3. Use mandrel to lock adjusting lever in position.
4. Remove drive belt.
5. Check cleanness of belt pulleys.
6. Fit new drive belt.
7. Remove mandrel.
Final steps
1. Install protective cover.
2. Install screws of protective cover.
3. Install safety equipment (if fitted).
4. Check function of safety equipment (if fitted).
98 | Task Description | MS150094/01E 2012-08
TIM-ID: 0000007424 - 003
