7.18 Belt Drive
7.18.1 Drive belt – Condition check
Preconditions
Engine is stopped and starting disabled.
Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt B Cracks on entire circumference Replace (→ Page 137)
Drive belt C Chunking
Drive belt Belt is oily, shows signs of over-
heating
136 | Belt Drive | MS150119/01E 2016-02
TIM-ID: 0000000920 - 011
