Sensors and actuators on engine free end
Item Name Monitoring of
1 B5.3 Lube oil pressure before filter (optional)
2 B5.2 Lube oil pressure after filter (optional)
3 B5.1 Lube oil pressure after filter
4 F33 Coolant level probe in expansion tank
5 B21 Seawater pressure (optional)
6 B6.2 Coolant temperature (optional)
7 B6.1 Coolant temperature
8 B34 Fuel pressure after filter
MS150119/01E 2016-02 | General Information | 39
TIM-ID: 0000055074 - 002
