Sensors and actuators on right side
Item Name Monitoring of
1 M52 Activation of exhaust gas recirculation (bypass at
ETC)
2 B33 Fuel temperature
3 Y45.1 Pressure regulating valve
4 A19 EIL electronic label
5 B16 Coolant pressure (optional)
6 M8 CR pump - activation of HP fuel control block
7 F46 Leak-off fuel level (optional)
8 B1 Camshaft speed, B side
9 Y27.2 4/2 directional control valve, B side
MS150119/01E 2016-02 | General Information | 41
TIM-ID: 0000055074 - 002
