7.4.3 Valve clearance – Check and adjustment
Preconditions
☑ Engine is stopped and starting disabled.
☑ Engine coolant temperature is max. 40 °C.
☑ Valves are closed.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Feeler gage
Y20010128 1
Torque wrench, 60–320 Nm
F30047446 1
Socket wrench, 24 mm
F30039526 1
Engine oil
Preparatory steps
1. Remove cylinder head cover (→ Page 179).
2. Install barring gear (→ Page 172).
3. The TDC mark (1) (if fitted) on the flywheel
must not be used for reference.
MS150109/01E 2015-11 | Task Description | 181
TIM-ID: 0000012225 - 005
