3.5 Main engine dimensions
Main engine dimensions
Engines with remote heat exchanger
Engine model Length (A) Width (B)
Height (C)
8V4000Mx4 approx. 2386 mm approx. 1613 mm approx. 1959 mm
70 | Technical Data | MS150109/01E 2015-11
TIM-ID: 0000045096 - 002
