Configuration of the terminal
System settings
Calls up the screen for calibrating the speed sensor.
Calls up the screen with the counters.
The following parameters can be configured on this screen:
Source for the speed signal.
Sensor - A speed sensor is connected to the terminal. The work screen
displays the icon: .
CAN-Bus - The speed signal is received through the CAN bus.
Number of impulses sent by the speed sensor over a distance of 100m.
(Only appears when "Sensor" is selected as the speed signal.)
Source for the work position signal.
Sensor - A work position sensor is connected to the terminal. The start
screen displays the icon: /
CAN-Bus - A work position signal is received through the CAN bus.
No selection - A work position signal was not selected.
Calibrating the speed sensor
When calibrating the speed sensor, you determine the number of pulses sent by the sensor over a
distance of 100m.
If the number of pulses is known, the terminal can calculate the current speed and transmit it to the
connected job computer.
To calibrate the speed sensor:
The terminal is connected to the tractor signal socket.
In the "Speed signal" parameter, the "Sensor" value is selected.
1. Measure and mark a distance of 100 m. The ground must correspond to the field conditions. The
distance should therefore lead over a meadow or a field.
2. Position the vehicle with connected implement at the beginning of the marked distance.
3. > - Open the vehicle screen.
