4. SPECIFICATIONS
Models
MP780083
Input Voltage Range 100 – 240VAC
No Load Input Current at 230VAC
≤150mA
Full Load Input Current at 230VAC
≤
500mA
AC input Frequency 50 – 60 Hz~
Efficiency
≥78%
Power Factor
≥0.9
Constant Voltage and Current Range Selection:
0.5-36V / 0-5A
Auto range with maximum output power 80W (V x A
≤
80W)
Constant Voltage Characteristics:
Adjust Resolution 10mV
Load Regulation (10 – 90%)
≤30mV
Line Regulation (±10%)
≤4mV
Ripple & Noise (peak-peak)
≤35mA
Constant Current Characteristics:
Adjust Resolution 10mA
Load Regulation (10 – 90%)
≤10mA
Line Regulation (±10%)
≤10mA
Voltmeter & Ammeter Accuracy ±(0.5% +5counts)
User adjustable upper current & voltage limit Yes
Number of preset recalls of frequent use V&I setting 3
Remote Sensing Yes
Ramp Step Irregular Waveform functions
Number of Voltage Level Setting 10
Settable Output Time Period of each Voltage Level 0 to 1200 seconds
Remote Programmable / Control by PC Output ON/OFF, Voltage & Current Control, Selection of Voltage
and Current Preset, Programmable of cyclic output and data
logging of output, Upper Voltage & Current Limit control.
Protection Tracking Over Voltage Protection, Current Limiting Protection,
Short Circuit, Overload, Over Temperature, Upper Voltage Limit,
Upper Current Limit.
Standard Communication Port USB 2.0
Optional Interface (not included)
Ethernet, Factory or User install
Additional Function Master/Slave Control
Cooling Method Natural Convection
Dimensions (WxHxD) 53.5x127x330mm 2x5x13 inch
Weight Approx. 1.9kgs 4.2lbs
◘ All values are based on the Standard ambient Temperature 25°C and Pressure 0.1Mpa.
◘ SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE
