3.2 Rear Panel
123546
789
10
3.2.1 MD-1000I
1 USB port
2 Battery pack connector
3 Power input
4 Communication interface
5 Two programmable outputs
6 UPS output
7 Input circuit breaker
8 Fan
9 Emergency power off (EPO) port
10 RS-232 port
Fig. 3-2 - 3 MD-1000I rear panel
