multimatic MD-3000I - Equipment Connection Sequence

MD-1000I / MD-2000I / MD-3000I UPS Installation and Hook-Up
6.3 Equipment Connection Sequence
 Connect the UPS to source of power, but make sure the power source and
the UPS are both reliably shut down.
 Before connecting equipment to the UPS outlet, you must perform the ini-
tial configuration.
 Connect the equipment to the UPS, making sure that all the equipment is
turned off.
6.3.1 EPO connection configuration
Function Connection wire gauge Suggested gauge
EPO 4 - 0.32 mm
2
(12 - 22 AWG )
0.82 mm
2
(18 AWG)
MD Series 63
Leave the EPO p
lug installed on the UPS' EPO port, even if you don't plan to
use the EPO function.
Fig. 6-3 -
1 EPO plug
Follow
the instructions for the EPO port as stated in Chapter 3.2.5 EPO port.
