Clean Blended Ice Machine (BIM-8) (continued)
©McDonald’s Corporation · Planned Maintenance Manual · July 2009 Page 2 of 4
Blended Ice Machine Model MS-8-1H
Weekly
BE 23 W1
5
Connect cleaning tubes.
Connect one tube from the
cleaning manifold to each
inlet line.
6
Place tubes in WASH bucket.
Insert the free end of the tubes
into the bucket of clean APSC
solution.
SolidSense APSC solution
7
Position cleaning pitcher.
Place cleaning pitcher on
pitcher pad.
8
Press Next.
The message window will
display: “APSC cleaning of
Strawberry Banana Line”,
then change to the next flavor
until all lines have been
cleaned. If cleaner solution
runs low, press Pause, refill
the bucket with cleaner
solution and press Resume.
After the last line is cleaned,
the next cleaning screen will
appear.
9
Place tubes in RINSE bucket.
Remove tubes from the
bucket of APSC solution and
place into the warm water
RINSE bucket.
10
Press Next.
The message window will
display: “Rinse of Strawberry
Banana Line”, then change to
the next flavor until all lines
have been rinsed. If water
runs low, press Pause, refill
the bucket with warm water
and press Resume. After the
last line is cleaned, the next
cleaning screen will appear.
11
Place tubes in SANITIZE
bucket.
Remove tubes from warm
water RINSE bucket and
place into the SANITIZE
bucket.
McD Sanitizer solution
12
Press Next.
The message window will
display: “Sanitizer fill of
Strawberry Banana Line”,
then change to the next flavor
until all lines have been
sanitized. If sanitizer solution
runs low, press Pause, refill
the bucket with sanitizer
solution and press Resume.
13
1 Minute Sanitizer Hold
After the last line is sanitized,
“1 Minute Sanitizer Hold”
will appear for one minute,
and then the next cleaning
screen will appear.
14
Remove tubes from SANITIZE
bucket.
15
Press Next.
The message window will
display: “Auto purge of
Strawberry Banana Line”,
then change to the next flavor
until all lines have been
purged. The next cleaning
screen will appear.
16
Disconnect cleaning tubes.
Disconnect the cleaning tubes
from each product line.
Chemicals
Chemicals
continued 
