22.2. Pre-set mixers
This table contains definitions of all the pre-defined mixers provided by the ROYAL SX. The following are listed:
 the name of the mixer
 the mixer inputs
 the mixer input switch
 the symbol for the mixer input’s method of working
Elevator compensation mixers for cruciform and T-tail
¡Define mixer
¨Exit
Name ELEVATR+
1 Elevator ON š
2 Spoiler ON œ
3 Flap ON š
4 Thr -Tr ON ›-
5 ------- ---- ---
Elevator compensation mixers for V-tail
¡Define mixer
¨Exit
Name V-TAIL+
1 Elevator ON š
2 Rudder ON š2
3 Spoiler ON œ
4 Flap ON š
5 Thr -Tr ON ›-
Delta mixer with throttle compensation input
¡Define mixer
¨Exit
Name DELTA+
1 Aileron ON ™2
2 Elevator ON š
3 Thr -Tr ON ›-
4 ------- ---- ---
5 ------- ---- ---
Mixer for outboard flaps (ailerons), four-flap model
¡Define mixer
¨Exit
Name AILERON+
1 Aileron ON ™2
2 Spoiler ON ›+
3 Flap ON š
4 Ele -Tr Mx1 š
5 -------- ---- ---
Mixer for inboard flaps (Flap), four-flap model
¡Define mixer
¨Exit
Name FLAP+
1 Flap ON š
2 Spoiler ON ›+
3 Aileron ON š2
4 Ele -Tr Mx1 š
5 -------- ---- ---
