LD6 RIDE-ON POWER TROWEL • OPERATION MANUAL — REV. #0 (02/10/20) — PAGE 17
LIFTING AND TRANSPORTING
TRANSPORTING THE TROWEL
After the trowel has been lifted onto a flatbed truck, do
the following:
1. Locate the tie-down symbols (Figure 4) on each side
of the trowel.
Figure 4. Tie-Down Symbol
2. Attach suitable tie-down straps to the locations marked
by the tie-down symbols. Be sure to connect the
tie-down strap hooks directly to the trowel as shown
in Figure 5. DO NOT wrap the tie-downs around the
frame as shown in Figure 6.
Figure 5. Tie-Down Method (Correct)
NOTICE
Use tie-downs with flat hooks or U-hooks only.
CORRECT
P/N 42971
Figure 6. Tie-Down Method (Incorrect)
3. Secure the trowel to a flatbed with the tie-down straps,
making sure they are properly tied to prevent movement
of the trowel during transport.
INCORRECT
