MULTIQUIP LD6 - Electrical Wiring Diagram (Power and Ground)

LD6 RIDE-ON POWER TROWEL • OPERATION MANUAL — REV. #0 (02/10/20) — PAGE 53
ELECTRICAL WIRING DIAGRAM (POWER AND GROUND)
STARTER
SOLENOID
LT. BLUE/PINK
18 AWG
T1
T1
+
-
T15
T17
T2
T2
T16
TO GROUND
BUS
TO HARNESS
SPLICE
BLACK
6 AWG
BLACK
14 AWG
TO FRAME
GND.
RED
4 AWG
RED
14 AWG
SPARK
PLUG
IGNITION
COIL
UNIT
CHASSIS
GROUND
3
2
1
4
5
6
KEY SWITCH
REAR VIEW
START
A
BB
TO GROUND
BUS
TO HARNESS
SPLICE
BLACK/YELLOW 18 AWG
GND KILL RELAY
30
GND
85
IGN
87A 87 86
GND GND
P3
T18
BLACK 18 AWG
PINK 18 AWG
BLACK 18 AWG
Y
+12 VDC BATTERY
J
