LD6 RIDE-ON POWER TROWEL • OPERATION MANUAL — REV. #0 (02/10/20) — PAGE 19
DIMENSIONS
Figure 7. LD6 Dimensions
A
C
B
Table 5. LD6 Dimensions
Designator Dimension in. (mm)
A Length 77.4 (1,966)
B Width 37.0 (939.8)
C Height 56.0 (1,422)
