MULTIQUIP LD6 - Electrical Wiring Diagram (Optional Spray Kit)

PAGE 52 — LD6 RIDE-ON POWER TROWEL • OPERATION MANUAL — REV. #0 (02/10/20)
ELECTRICAL WIRING DIAGRAM (OPTIONAL SPRAY KIT)
P3
LH SPRAY SWITCH
B
SPRAY PUMP
U
1 2
+12 VDC
PWR
P2
F1
5A
RH SPRAY SWITCH
X
1 2
+12 VDC
PWR
BLACK
RED
M
1 2
P4
F
1 2
18 AWG
RED/WHITE
18 AWG
RED/WHITE
18 AWG
RED/WHITE
18 AWG
RED/WHITE
18 AWG
RED/WHITE
16 AWG
BLACK
18 AWG RED/WHITE
18 AWG
BLACK
18 AWG BLACK
16 AWG
BLACK
P1
CONNECT TO
PITCH KIT HARNESS
OR LIGHT KIT HARNESS
ACCESSORY POWER
